World Club Champion Football Serie A 2001-2002 DIMM FIRM Ver.3.03 (CDP-10003)
From Citylan
Jump to navigationJump to search
| dumper | |
| date | 18/06/2016 |
| emulator | MAME 0.175 |
| dev | MetalliC |
| name | wccf1dup on ProgettoEMMA wccf1dup on Arcade Database |
| description | World Club Champion Football Serie A 2001-2002 DIMM FIRM Ver.3.03 (CDP-10003) |
| year | 2002 |
| manufacturer | Sega - Hitmaker |
Technical references
CPUs
| QTY | Type | clock | position | function |
|---|---|---|---|---|
| 1x | PIC16C621A | (317-0329-JPN)(253-5508-0329J) | 8bit CMOS Microcontroller (internal ROM extracted) |
ROMs
| QTY | Type | position | status |
|---|
RAMs
| QTY | Type | position |
|---|
PLDs
| QTY | Type | position | status |
|---|
Others
It's just a cd running on WCCF server pc that will upgrade all the satellites and the main screens Naomis Dimm board to firmware 3.03
The upgrade firmware programm is encrypted with WCCF 01-02 JP key (I don't know if it was brute forced or not)
Notes
It's a NAOMI 2 Satellite Terminal disk.
Disk type: CD
Disk N°: CDP-10003
Disk ID: BEG
Key: E5D343B65723BCBC
Files
-
disk front 1
-
disk front 2
-
disk front 3
-
disk back 1
-
disk back 2
