World Club Champion Football European Clubs 2004-2005 Ver.1.1 (Export) (CDV-10015)
From Citylan
Jump to navigationJump to search
dumper | f205v |
date | 17/07/2012 |
emulator | MAME 0.169 |
dev | MetalliC |
name | wccf331e on Arcade Database |
description | World Club Champion Football European Clubs 2004-2005 Ver.1.1 (Export) (CDV-10015) |
year | 2005.06 |
manufacturer | Sega |
Technical references
CPUs
QTY | Type | clock | position | function |
---|---|---|---|---|
1x | PIC16C621A | (317-0419-EXP)(253-5508-0419E) | 8bit CMOS Microcontroller (internal ROM extracted) |
ROMs
QTY | Type | position | status |
---|
RAMs
QTY | Type | position |
---|
PLDs
QTY | Type | position | status |
---|
Others
Notes
It's a NAOMI 2 Satellite Terminal disk.
Disk type: CD
Disk N°: CDV-10015
Disk ID: BEG
Key: CEC7BA541A371AF2
Uses 837-14229 camera PCB
