Vapor Trail - Hyper Offence Formation (World revision 3?)
From Citylan
Jump to navigationJump to search
| dumper | f205v, Tirino73 |
| date | 23/03/2010 |
| emulator | MAME 0.137u2 |
| dev | f205v, Tirino73 |
| name | vaportra3 on ProgettoEMMA vaportra3 on Arcade Database |
| description | Vapor Trail - Hyper Offence Formation (World revision 3?) |
| year | 1989 |
| manufacturer | Data East |
Technical references
CPUs
| QTY | Type | clock | position | function |
|---|
ROMs
| QTY | Type | position | status |
|---|
RAMs
| QTY | Type | position |
|---|
PLDs
| QTY | Type | position | status |
|---|
Others
Notes
This romset comes from an original pcb.
Hardware is the same of other versions.
On this pcb sound code and ADPCM roms was been renamed "FL0X" instead of FJ0X" as reported on stickers, and MAA-00 mask (characters & tiles 1) data was been splitted into four 128kb roms.
Rom definition:
FL00-3, FL02-3 part of main program
FL05, FL06 Oki 6295 ADPCM samples *Update: 541001 (see below) with data identical of existing set,so removed
FL23 to FL26 chars & tiles 1
Eproms/roms are 27c1001,531001
and *Update: 541001 (FL23 to FL26) -> OTPROM version of 571001 with same -non- Jedec pinout (pin 2 and pin 24 swapped)
Rest of eproms/roms/mask are identical of existing set
