| dumper | f205v |
| date | 24/09/2017 |
| emulator | |
| dev |
| name | 1564 |
| description | Unknown - Blister PLDs |
| year | 199x |
| manufacturer |
Technical references
CPUs
| QTY | Type | clock | position | function |
|---|
ROMs
| QTY | Type | position | status |
|---|
RAMs
| QTY | Type | position |
|---|
PLDs
| QTY | Type | position | status |
|---|---|---|---|
| 2x | I(ntel) P5C060-45 | L1120345 | dumped |
| 1x | ALTERA EP600PC-3 | 2G19001 | dumped |
| 1x | ALTERA EP610PC-35 | 4E19007 | read protected |
| 2x | EP510PC-35 | 4?19007 ??19007 | read protected |
Others
Notes
Blister only, no PCB
I(ntel) P5C060-45 L1120345 ALTERA EP610PC-35 4E19007 ALTERA EP600PC-3 2G19001 ALTERA EP510PC-35 4x19007 ALTERA EP510PC-35 xx19007 I(ntel) P5C060-45 L1120345
Files
-
PLDs
-
readme
-
ROMs
1564
