Chihiro Firmware Update For Compact Flash Box (4.01) (GDX-0024A)
From Citylan
Jump to navigationJump to search
| dumper | Rtw |
| date | 18/10/2012 |
| emulator | MAME 0.154 |
| dev | R. Belmont |
| name | ccfboxa on Arcade Database |
| description | Chihiro Firmware Update For Compact Flash Box (4.01) (GDX-0024A) |
| year | 2009.03.31 |
| manufacturer | Sega |
Technical references
CPUs
| QTY | Type | clock | position | function |
|---|---|---|---|---|
| 1x | PIC16C621A | (317-0567-EXP)(253-5508-0567) | 8bit CMOS Microcontroller (internal ROM extracted) |
ROMs
| QTY | Type | position | status |
|---|
RAMs
| QTY | Type | position |
|---|
PLDs
| QTY | Type | position | status |
|---|
Others
Notes
It's a Chihiro disk.
Disk type: CD
Disk N°: GDX-0024A
Disk ID: BRN
Key: D96446469BDCE9C1
Listing of cdrom
Title BOX GDROM CF-BOX FIRM Media ID EB08 Media Config GD-ROM1/1 Regions J Peripheral String 0000000 Product Number GDX-0024A Version V2.000 Release Date 20090331 Manufacturer ID TOC DISC Track Start Sector End Sector Track Size track01.bin 150 8740 20206032 track02.raw 8891 10242 3179904 track03.bin 45150 549299 1185760800 FIRM UPDATE FOR CF-BOX GDX-0024A PIC16C621A () Sticker: 235-5508-0567 VER0001, TEST_OK, BRN.BIN, '70 1F 71 1F' D96446469BDCE9C1
Files
-
disk front
-
