Kick '4' Cash (Export)

From Citylan
Jump to navigationJump to search
EMU Infos
dumper f205v
dump date 02/11/2009
emulator
dev
PCB Infos
name 861
description Kick '4' Cash
year 2004
manufacturer Sega

Technical references

CPUs

QTY Type clock position function
1x oscillator 50.000

ROMs

QTY Type position status
1x M27C322 epr24212.ic11 dumped
16x M27W064 opr24213a-opr24216a, opr24224a-opr24235a not dumped yet

RAMs

QTY Type position
1x IDT71256 ic15

PLDs

QTY Type position status

Others

Notes

Working
Cart type: 171-7978B
Cart N°: 840-0140C
EPR: 24212
Protection IC: ACTEL A54SX32A (317-0397-COM)

Files


861
