EMU Infos
dumper
date 28/12/2004
emulator
dev
PCB Infos
name 89
description Pull Down
year 1978
manufacturer E&E Automaten

Technical references

CPUs

QTY Type clock position function
1x oscillator unmarked

ROMs

QTY Type position status

RAMs

QTY Type position
1x N82S16

PLDs

QTY Type position status

Others

1x 22x2 edge connector
2x trimmer (volume)
1x 4 DIP switches bank
2x switches

Notes

No CPU, NO ROM
PCB is marked: "050507 PULL-DOWN"
PCB is labeled: "521111263"
