Revision as of 07:34, 16 February 2018
| dumper | f205v |
| date | 22/06/2017 |
| emulator | MAME 0.35b9 |
| dev | Paul Leaman |
| name | teamqb on ProgettoEMMA teamqb on Arcade Database |
| description | John Elway's Team Quarterback (set 1) |
| year | 1988 |
| manufacturer | Leland |
Technical references
CPUs
| QTY | Type | clock | position | function |
|---|
ROMs
| QTY | Type | position | status |
|---|---|---|---|
| 1x | 27C64 | u3 | dumped |
| 9x | 27C128 | u67,u68,u69,u70,u90,u92,u93,u94,u95 | dumped |
| 11x | 27C512 | u2t,u3t,u8t,u58t,u59t,u13t,u14t,u15t,u25t,u26t,u27t | dumped |
RAMs
| QTY | Type | position |
|---|
PLDs
| QTY | Type | position | status |
|---|
Others
Notes
Blister only, no PCB
label format is: ------------------------ | (C)1988 Leland Corp. | -> copyright | P/N 03-15600-01 | -> part number | TEAM QB U3 | -> game name and position ------------------------
Files
-
EPROMs
1537
