EMU Infos
dumper f205v
date 17/01/2016
emulator MAME 0.171
dev Roberto Fresca
PCB Infos
name chryglda on ProgettoEMMA
chryglda on Arcade Database
description Cherry Gold I (set 2, encrypted bootleg)
year 1998
manufacturer

Technical references

CPUs

QTY Type clock position function
1x TMPZ84C00AP-6 u15 8-bit Microprocessor - main
3x D71055C u30,u39,40 Programmable Peripheral Interface
1x WF19054 u27 Programmable Sound Generator - sound
1x SN76489AN u28 Digital Complex Sound Generator - sound
1x oscillator unmarked Y1

ROMs

QTY Type position status
1x D27256 1.u3 dumped
1x AM27512 3.u22 dumped
1x D27C010 2u6 dumped
1x N82S147AF u1 dumped

RAMs

QTY Type position
4x HM6116LP-4 u9,u10,u11,u12
1x D4016C-1 u23

PLDs

QTY Type position status
1x unknowun Cl-001 (QFP144) CY144A read protected
4x GAL20V8A-15LNC pl1,pl4,pl5,pl6 read protected
2x PALCE20V8H-25PC/4 u2,u? read protected
1x PALCE22V10H-25PC/4 u? read protected

Others

1x 36x2 edge connector
1x 10x2 edge connector
1x pushbutton (TS)
2x trimmer (volume)(VR1,VR2)
5x 8x2 switches DIP(SW1-5)
1x battery 5,5V

Notes

PCB is marked "REV.3"

Files
